Thrust Atlas: rocket engines in 3D
An interactive guide to five rocket engines, with 3D models, propellant-cycle explanations, and historical photographs.
○Open
⊠Login
$Paid
†Ads
✦Pretty
●Pro
◎Niche
◉Human
⚑Risk
ƒJS
- For
- Rocket-engine and spaceflight learners
- Worth noticing
- The collection spans Goddard’s 1926 Nell through the Raptor 3 configuration publicly revealed in 2024.
Field notes
The F-1 exhibit combines controls for solid and exploded views, exhaust, and labels with separate overview, flow, parts, and image sections. Its cycle explanation follows the gas generator, turbine, and pumps before describing combustion in the main chamber. The site credits NASA photographs and links to further reading; it also notes that the reconstructions are artist models, with approximate locations and no common physical scale.
